Meitrack T622G
Vehicle GPS Tracker
The T622G is a brand new high-end vehicle GPS tracker with market-proven quality and precise positioning. In addition to real-time tracking, it supports various peripherals and can be installed into taxies, freight cars, and buses.
| FEATURES |
 |
3G (WCDMA) network Full band worldwide roaming, 3G/2G auto switch. |
 |
Harsh acceleration/braking alarm Within 3-axis accelerometer, harsh acceleration/braking alarm can be realized. |
|||
 |
Garmin Fleet Tracking Streamline dispatching with Garmin intergration to further improve business efficiency. |
 |
Multi-functional Support CAN bus, camera, LED display, fuel/temperature sensor, iButton. |
|||
| APPLICATIONS |
| SPECIFICATIONS |
| Dimension | 105 mm x 65 mm x 26 mm | Weight | 190g | ||||
| Power supply | DC 11–36 V/1.5 A | Backup battery | 400 mAh/3.7 V | ||||
| Power consumption | Current in standby mode: 65mA | Operating temperature | -20°C to 55°C | ||||
| Operating Humidity | 5% to 95% | Working hour | 53 hours in power-saving mode 5.5 hours in normal mode |
||||
| LED indicator | Green indicator showing the GSM signal Blue indicator showing the GPS signal |
Button/Switch | 1 power button | ||||
| Memory | 8 MB buffer | Sensor | 3-axis accelerometer (used to wake the device up by vibration and detect towing alarms) | ||||
| Positioning accuracy | 2.5m | GPS sensitivity | -161 dB | ||||
| Frequency band | WCDMA frequency band: Five band 800/850/900/1900/2100MHz GSM frequency band: Quad band 850/900/1800/1900MHz |
I/O port | 3 digital inputs (1 negative trigger, 1 positive trigger, and 1 positive/negative selectable trigger) 2 analog detection inputs 2 outputs 1 RS232 EXT port 1 RS232/485 port 1 USB port 1 CAN bus interface 1-Wire® temperature sensor 1-Wire® iButton |
| ACCESSORIES |
| Accessories | T622G with a built-in battery | GPS antenna | 3G antenna | CD download card | |||||
| USB cable | I/O cable | ||||||||
| Optional Accessories | A53 fuel level sensor | iButton | Camera | LED display | |||||
| Garmin navigator | LLS sensor | A76 ultrasonic fuel sensor | A52 digital temperature sensor + A61 sensor box |
| CERTIFICATES |
