car gps tracker

FEATURES

Smiley face
Built-in LoRa
The T399G and K211G communicate with each other, making the smart logistics network a reality.
Smiley face
Flexible configurable I/O
Offer outstanding configuration flexibility to cater to a wide variety of requirements.
1
IP67 water resistant
Specialized design provides a tough casing that stands up to the elements.
screen
Driving behavior analysis
Detect driver behaviors, such as the driver fatigue, idling, harsh acceleration/braking, harsh cornering, collision, etc.

APPLICATIONS

T399G-A

SPECIFICATIONS

Dimension 80.5 mm x 60 mm x 23.5 mm
Weight 100g
Power supply DC 11–36 V/1.5 A
Power consumption Current in standby mode: 65 mA
Operating temperature -35°C to 80°C (available for the device without a battery)
Operating humidity 5% to 95%
LED indicator Green indicator showing the network signal
Blue indicator showing the GPS signal
Button/Switch 1 upgrade button (used to manually upgrade the firmware)
1 power button
Memory 8 MB buffer
Sensor 3-axis accelerometer (used to wake the device up by vibration and detect towing alerts, harsh acceleration alerts, and harsh braking alerts)
LoRa communication distance At most 20 meters (obtained from actual tests in trucks’ containers)
LoRa working frequency 137–1020 MHz (433 MHz by default)
LoRa antenna Built-in spring antenna
Frequency band T399G-E:
UMTS/HSDPA: 900/2100 MHz
GSM/GPRS: 900/1800 MHz
T399G-A:
UMTS/HSDPA: 850/1900 MHz
GSM/GPRS: 850/900/1800/1900 MHz
T399G-T:
UMTS/HSDPA: 850/2100 MHz
GSM: 850/900/1800/1900 MHz
Positioning accuracy 2.5m

ACCESSORIES

T399G Tracker L wrench Hexagon screw
400 mAh battery (-20°C to 60°C) CD download card

OPTIONAL ACCESSORIES

A52 digital temperature sensor A53 fuel level sensor A64 remote control receiver
A67 remote control Relay (12 V/24 V) External GPS antenna
Ultrasonic fuel level sensor RFID Buzzer
USB cable iButton reader LED display
400 mAh high-temperature battery

CERTIFICATE

CE
