Wireless GPS Tracker Meitrack TC68SL
4G Plug & Play Wireless GPS Tracker
The TC68SL is a 4G plug & play wireless GPS tracker, which supports vehicle positioning, live tracking, and anti-theft functions.
With a standard OBD II plug, it can be easily installed. The device has an internal battery that supplies power to it for a limited time period. When the device is removed, an instant alert will be received. It is a perfect choice for private cars and other motor vehicles equipped with an OBD II connector.
Download TC68SL Flyer>>
Download TC68SL CD>>



FEATURES



obd-2 Plug & play
This tracker with OBD connector can be fastly and easily installed.
WiFi 4G WiFi hotspot
Act as an in-vehicle WiFi hotspot, up to 8 WiFi enabled devices.
SOS SOS button
An instant alert will be received when the SOS button is pressed.
obd-3 Disconnect alert
When the device is removed from the OBD connector, an alert will be generated.



APPLICATIONS



APP-1

SPECIFICATIONS



Dimension 67 mm x 51 mm x 23.5 mm Weight 60g
Power supply DC 11.5–36 V / 1 A Backup battery 110 mAh/3.7 V
Battery life Power-saving mode: 12 hours
Normal working mode: 1 hour
Power consumption Current in standby mode: 100 mA
Operating temperature -20℃ to 55℃ Operating humidity 5% to 95%
LED indicator 2 LED indicators showing GSM and GPS status Button/Switch 1 SOS button
Microphone Internal microphone Memory 8 MB buffer
Sensor 3-axis accelerometer Frequency band TC68SL-E:
GSM:900/1800MHz, WCDMA:B1/B5/B8, FDD:B1/B3/B5/B7/B8/B20, TDD:B38/B40/B41
TC68SL-A:
WCDMA:B2/B4/B5, FDD:B2/B4/B12
TC68SL-J:
WCDMA:B1/B6/B8/B19, FDD:B1/B3/B8/B18/B19/B26, TDD:B41
TC68SL-AU:
GSM:850/900/1800/1900MHz, WCDMA:B1/B2/B5/B8, FDD:B1/B2/B3/B4/B5/B7/B8/B28, TDD:B40
GPS sensitivity -161 dB  Positioning accuracy  2.5m
 I/O port 1 USB port WiFi function (optional) 2.4 GHz WiFi hotspot



ACCESSORIES



Accesories TC68SL Tracker USB cable CD download card
Optional Accessories OBD extension cord Velcro



CERTIFICATES



CE
