FEATURES

[/fusion_text][/one_full][one_third last=”no” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

Built-in Front & Rear Cameras
Record what happens on the road and in the cabin.

[/fusion_text][/one_third][one_third last=”no” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

Easy to Install
Simple wiring, compact size and light weight.

[/fusion_text][/one_third][one_third last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

Adaptive ADAS & DMS Algorithms
No manual measurement is needed.

Additional AHD Camera (Optional)
Fulfill more demands on video recording.

RS232 Interface (Optional)
Unleash more possibilities.

Stable Performance Under High Temperature
Greatly improve user experience.

[/fusion_text][/one_third][fusion_text][/fusion_text][one_full last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”” padding=”” margin_top=”” margin_bottom=”” animation_type=”” animation_direction=”” animation_speed=”0.1″ class=”” id=””][fusion_text]

DOWNLOAD

[/fusion_text][/one_full][one_half last=”no” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”10px” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

[/fusion_text][/one_half][one_half last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”10px” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

[/fusion_text][/one_half][one_full last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”” padding=”” margin_top=”” margin_bottom=”” animation_type=”” animation_direction=”” animation_speed=”0.1″ class=”” id=””][fusion_text]

SPECIFICATIONS

[/fusion_text][/one_full][one_half last=”no” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][accordian class=”” id=””][toggle title=”Power supply” open=”no”]

	Rated voltage		DC: 12-24V
	Power consumtipon		500mA

[/toggle][toggle title=”AI” open=”no”]

AI Video

ADAS, DMS

[/toggle][toggle title=”Storage medium” open=”no”]

TF card

Up to 256 GB, class 10 and above, FAT32 format

[/toggle][toggle title=”Audio and video” open=”no”]

	Video input		Built-in ADAS front camera and DMS rear camera
	Video output		Resolution: ADAS 720P; DMS 1080P
	Video search and playback		Retrievable playback by channel, video type and time
	Video compression		H.264
	Audio input		Built-in MIC, mono
	Audio output		Built-in speaker, mono
	Audio compression		PCM, WAV
	Recording method		Normal recording and AI alarm recording; Audio and video recorded simultaneously

[/toggle][toggle title=”Frequency band” open=”no”]

	MD101-E		WCDMA: B1/B5/B8 LTE-FDD: B1/B3/B7/B8/B20/B28 LTE-TDD: B38/B40/B41
	MD101-A		WCDMA: B2/B4/B5 LTE-FDD: B2/B4/B12
	MD101-AU		GSM: B2/B3/B5/B8 WCDMA: B1/B2/B5/B8 LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28 LTE-TDD: B40
	MD101-J		WCDMA: B1/B6/B8/B19 LTE-FDD: B1/B3/B8/B18/B19/B26 LTE-TDD: B41

[/toggle][/accordian][/one_half][one_half last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][accordian class=”” id=””][toggle title=”System structure” open=”no”]

Operation system

Linux

[/toggle][toggle title=”Protocol” open=”no”]

Protocol supported

JT/T 1078-2016, JT/T808-2019

[/toggle][toggle title=”WiFi/GNSS” open=”no”]

	WIFI		Internal WiFi module. Only for connecting to APP
	Positioning mode		GPS & BD
	Positional accuracy		5 m
	Sensitivity		-162 dBm
	GNSS antenna		External GPS antenna

[/toggle][toggle title=”Other” open=”no”]

	Operating temperature		-20°C to 70°C (without battery)
	I/O port		4 x Din (ACC/SOS/left-turn signal/right-turn signal);
	RS232 (optional)		Only the Thai DLT certification
	Sensor		Built-in 3-axis accelerometer
	Outer case		Dimensions: 116 mm x 66 mm x 38 mm
	Weight		198g

[/toggle][/accordian][/one_half][one_full last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”” padding=”” margin_top=”” margin_bottom=”” animation_type=”” animation_direction=”” animation_speed=”0.1″ class=”” id=””][fusion_text]
