Meitrack T1

Glonass/ GPS Fleet Tracking Device

The T1 is a high-end Glonass/ GPS fleet tracking device with market-proven quality and precise positioning. In addition to real-time tracking, it supports various peripherals. The tracking device can apply for taxies, freight cars, and buses.

Download T1 Flyer>>
Download T1 CD>>

FEATURES



tire Tire Pressure Monitoring
Fully integrated for tire pressure monitoring system to enhance safety of your fleet.
can CAN bus interface (Optional)
Compatible with Inventure CAN bus interface which can read CAN data of various vehicle models.
io Multifunctional
Support camera, RFID, LCD/LED display, fuel/temperature sensor, and iButton driver ID.
alert Multiple alerts & reports
Support speeding/towing/geo-fence alerts, cornering/mileage reports etc.



APPLICATIONS

T1

SPECIFICATIONS



Dimension 105 mm x 65 mm x 26 mm Weight 190g
Power supply DC 11–36 V/1.5 A  Backup battery 400 mAh/3.7 V
Power consumption Current in standby mode: 65 mA  Working hour 61 hours in power-saving mode and 5.7 hours in normal mode
Operating temperature -20°C to 55°C Operating humidity 5% to 95%
GPS sensitivity -161 dB LED indicator Green indicator showing the GSM signal
Blue indicator showing the GPS signal
Button/Switch 1 SOS button (for sending SMSs or dialing)1 power button Storage 8 MB butter
Sensor 3-axis accelerometer (used to wake the device up by vibration and detect towing alerts) Frequency band GSM 850/900/1800/1900 MHz
Positioning accuracy 2.5m I/O port 3 digital inputs
(2 negative inputs and 1 positive input)
2 analog detection inputs
2 outputs
1 RS232 port
1 USB port
1-Wire® temperature sensor
1-Wire® iButton



ACCESSORIES



Accessories T1 with a built-in battery GSM antenna GPS antenna
I/O cable + SOS button CD download card USB cable
Optional Accessories Camera Handset RFID reader
iButton LED display A53 fuel level sensor
A52 digital temperature sensor + A61 sensor box Tire pressure sensor
CERTIFICATES



t1-1
