vehicle tracking device

FEATURES

Cost-effective
Cost-effective
Lower price and more diversified functions for your choice.
Smiley face
Built-in Bluetooth (optional)
Support multiple Bluetooth temperature and humidity sensors and beacons at one time.
1
IP67 Water Resistant
Specialized design provides a tough casing that stands up to the elements.
screen
Driving Behavior Analysis
Detect driver behaviors, such as the driver fatigue, idling, harsh acceleration/braking, harsh cornering, collision, etc.

APPLICATIONS

APP-EN

SPECIFICATIONS

Dimension 75 mm x 44 mm x 17 mm
Weight 77g
I/O power cable length 50cm
Power supply DC 11.4–90 V/1.5 A
Power consumption Current in standby mode: 65 mA
High temperature resistant battery 200mAh (Operating temperature: -5°C to 75°C)
Operating temperature -35°C to 80°C (for the device without a battery)
Operating humidity 5% to 95%
LED indicator Green indicator showing the network signal
Blue indicator showing the GPS signal
Button/Switch 1 upgrade button (used to manually upgrade the firmware)
1 power button
Memory 8 MB buffer
Sensor 3-axis accelerometer
Frequency band T711L:
GSM: 900/1800
LTE FDD: B1/B3/B7/B8/B20/B28
LTE TDD: B38/B40
Bluetooth 2.4G Internal Bluetooth module, compatible with Bluetooth 5.0 GHz
GPS sensitivity -165 dB
GNSS Dual-mode positioning (GPS/BeiDou/GLONASS)
Positioning accuracy 2.5 meters
I/O port 1 positive input by default (ACC)
1 analog detection input (0–30 V)
1 open collector
1 1-Wire port
1 debug interface (Micro USB)

ACCESSORIES

T711L tracker High temperature resistant battery (200 mAh) L wrench
Hexagon screw CD download card

OPTIONAL ACCESSORIES

Relay (12 V/24 V) A52 digital temperature sensor A53 fuel level sensor
Buzzer iButton reader USB cable
Bluetooth beacon Bluetooth temperature and humidity sensor

CERTIFICATE

CE, CITC, IP67
