FEATURES


[/fusion_text][/one_full][one_third last=”no” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”” padding=”” margin_top=”” margin_bottom=”” animation_type=”” animation_direction=”” animation_speed=”0.1″ class=”” id=””][fusion_text]

Up to 22400 mAh Battery
Solar panels and high-capacity batteries ensure battery life.

[/fusion_text][/one_third][one_third last=”no” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”” padding=”” margin_top=”” margin_bottom=”” animation_type=”” animation_direction=”” animation_speed=”0.1″ class=”” id=””][fusion_text]

WiFi/BLE Communication
Support WiFi positioning, Bluetooth temperature and humidity sensor and beacons.

[/fusion_text][/one_third][one_third last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

Magnetic Installation
Industrial magnets which facilitates it attach to flat metal surface.

[/fusion_text][/one_third][one_third last=”no” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

Smiley face
IP67 Water Resistant
Specialized design guarantees a stable operating performance.

[/fusion_text][/one_third][one_third last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

Smiley face
FOTA for Configuration
Automatic firmware and configuration update tool for Meitrack telematics device.

[/fusion_text][/one_third][one_full last=”no” spacing=”no” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

VIDEO


[/fusion_text][/one_full][one_full last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”10px” margin_bottom=”0px” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][slider width=”100%” height=”100%” class=”” id=””][slide type=”video”][/slide][/slider][fusion_text]

DOWNLOAD


[/fusion_text][/one_full][one_half last=”no” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”15px” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

[/fusion_text][/one_half][one_half last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”15px” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

[/fusion_text][/one_half][fusion_text][/fusion_text][one_full last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”30px” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

SPECIFICATIONS


[/fusion_text][/one_full][one_half last=”no” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”” padding=”” margin_top=”” margin_bottom=”” animation_type=”” animation_direction=”” animation_speed=”0.1″ class=”” id=””][accordian class=”” id=””][toggle title=”Physical specification” open=”no”]

Dimensions of the tracker
(excluding the charging cover)
71 mm × 95 mm × 27 mm (L × W × H)
Outer case material ABS

[/toggle][toggle title=”Power” open=”no”]

Operating voltage 3.7V
Minimum current in sleep mode 0.29mA
Built-in battery (optional) 3200 mAh/3.7V
Charging voltage Magnetic charging: 5.5 V/2 A
Charging by using a battery box (I/O cable): 11.4–60 V
Solar charging current Charging the tracker by using a solar panel: MAX 70 mA
Charging a battery box by using a solar panel: MAX 100 mA

[/toggle][toggle title=”Frequency band” open=”no”]

TA255E EGPRS: 850/900/1800/1900Mhz
Cat M1/Cat NB2:
LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B14 (Cat M1 only) / B18/B19/B20/B25/B26/B27 (Cat M1 only) /
B28/B66/B71 (Cat NB2 only) /B85
TA255L-E GSM:850/900/1800/1900MHz
LTE-FDD:B1/B3/B5/B7/B8/B20/ B28
TA255L-AU GSM:850/900/1800/1900MHz
LTE-FDD:B2/B3/B4/B5/B7/B8/B28/ B66

[/toggle][toggle title=”GNSS” open=”no”]

GPS mode Support GPS, BD and Glonass; support dual-mode combination configuration
Support LBS+WIFI assisted positioning
Positioning accuracy 2.5M
Tracking sensitivity -162dBm
GSM/GPS antenna GSM (internal FPC antenna), GPS (internal ceramic antenna)

[/toggle][toggle title=”Bluetooth ” open=”no”]Compliant with Bluetooth 5.0/4.2[/toggle][toggle title=”WiFi” open=”no”]802.11 b/g/n. Frequency: 2.4 GHz. STA mode supported[/toggle][toggle title=”Interface” open=”no”]

LED indicator Green LED indicator showing the GSM signal
Blue LED indicator showing the GPS signal
Red LED indicator showing the charging status
Dual sim card Dual card single waiting, Nano-sim and E-sim (reserved)
USB Micro-USB
Memory 8 MB flash

[/toggle][/accordian][/one_half][one_half last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”” padding=”” margin_top=”” margin_bottom=”” animation_type=”” animation_direction=”” animation_speed=”0.1″ class=”” id=””][accordian class=”” id=””][toggle title=”Function” open=”no”]

Sensor 3-axis accelerometer (used to determine whether the tracker vibrates, is moving, or stops moving)
Drop detection sensor
Scenarios Installation alert or drop alert
Solar charger
Attachable battery box
Round or polygonal geo-fence alert
Low power alert for a battery box
Cornering report
Speeding alert
Heartbeat report
Impact detection
Harsh cornering detection
Harsh acceleration and braking detection
Real-time location query, tracking by time interval, or tracking by distance
.Time Synchronization GNSS , NITZ
Firmware update FOTA, USB upgraded
Configuration Meitrack Manager (USB), MT Manager+ APP (Bluetooth), MS03 Platform, FOTA, SMS

[/toggle][toggle title=”Operating environment” open=”no”]

Operating temperature(built-in battery) -20℃~60℃
Storage temperature (exclude battery) -40℃-80℃
Water resistance rating IP67

[/toggle][toggle title=”Certification ” open=”no”]CE, IP67[/toggle][/accordian][/one_half][one_full last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”35px” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

STANDARD ACCESSORIES


[/fusion_text][/one_full][one_full last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”” padding=”” margin_top=”” margin_bottom=”” animation_type=”” animation_direction=”” animation_speed=”0.1″ class=”” id=””][images picture_size=”fixed” autoplay=”no” columns=”4″ column_spacing=”13″ scroll_items=”” show_nav=”yes” mouse_scroll=”no” border=”yes” lightbox=”no” class=”” id=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/1.TA255Seriestracker.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/2.Magneticchargingcover.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/3.Powercover.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/4.Lwrench.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/5.Hexagonscrew.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/6.CDdownloadcard.jpg” alt=””][/images][/one_full][one_full last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”15px” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

OPTIONAL ACCESSORIES


[/fusion_text][/one_full][one_full last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”” padding=”” margin_top=”” margin_bottom=”” animation_type=”” animation_direction=”” animation_speed=”0.1″ class=”” id=””][images picture_size=”fixed” autoplay=”no” columns=”4″ column_spacing=”13″ scroll_items=”” show_nav=”yes” mouse_scroll=”no” border=”yes” lightbox=”no” class=”” id=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/1.Batterybox1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/2.Battery1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/3.TA255magnetkit1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/4.TA255magnetinstallationkit1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/5.AST101Bluetoothtemperatureand1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/6.ELABluetoothtemperatureand1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/7.AB401Bluetoothbeacon1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/8.AB402Bluetoothbeacon1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/9.A53Fuellevelsensor1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/10.A52Digitaltemperaturesensor1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/11.ASUF103Bluetoothultrasonic1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/12.ASUF104Bluetoothultrasonic1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/13.ASUF105Ultrasonicfuel1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/14.A76Ultrasonicfuellevelsensor1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/15.Relay1224V1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/16.iButtonreader1.jpg” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/17.RFIDreader1.jpg” alt=””][/images][/one_full][one_full last=”yes” spacing=”yes” center_content=”no” hide_on_mobile=”no” background_color=”” background_image=”” background_repeat=”no-repeat” background_position=”left top” border_size=”0px” border_color=”” border_style=”solid” padding=”” margin_top=”15px” margin_bottom=”” animation_type=”0″ animation_direction=”down” animation_speed=”0.1″ class=”” id=””][fusion_text]

APPLICATIONS


[/fusion_text][images picture_size=”fixed” autoplay=”no” columns=”4″ column_spacing=”13″ scroll_items=”” show_nav=”yes” mouse_scroll=”no” border=”no” lightbox=”no” class=”” id=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/app1.ContainerShipping.png” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/app2.TrailerTracking.png” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/app3.FleetManagement.png” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/app4.CarRental.png” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/app5.WasteManagement.png” alt=””][image link=”” linktarget=”_self” image=”http://www.meitrack.com/wp-content/uploads/2023/04/app6.PalletTracking.png” alt=””][/images][/one_full]
