Meitrack T333L
4G Vehicle GNSS Tracker
4G Vehicle GNSS Tracker
The T333L is a brand new 4G vehicle tracker. In addition to real-time tracking, the device has two-way calling and remote listen-in functions. It provides excellent and stable performance in vehicle tracking and fleet management.
FEATURES
Cost-effective
Lower price and more diversified functions for your choice.
Lower price and more diversified functions for your choice.
Two-way Communication
External speaker and microphone, two-way communication can be realized.
External speaker and microphone, two-way communication can be realized.
Multifunctional
Support camera, fuel/temperature sensor, LED display, RFID/iButton and etc.
Support camera, fuel/temperature sensor, LED display, RFID/iButton and etc.
Driving Behavior Analysis
Detect driver behaviors, such as the driver
fatigue, idling, harsh acceleration/braking, harsh cornering, collision, etc.
Detect driver behaviors, such as the driver
fatigue, idling, harsh acceleration/braking, harsh cornering, collision, etc.
APPLICATIONS
SPECIFICATIONS
| Dimension | 105 mm x 65 mm x 26 mm | ||
| Weight | 190g | ||
| Power supply | DC 11–36 V/1.5 A | ||
| Backup battery | 400 mAh/3.7 V | ||
| Power consumption | Standby mode: 5mA Normal mode: 65mA |
||
| Working hour | 47 hours in power-saving mode 4.7 hours in normal mode |
||
| Operating temperature | -20°C to 55°C (normal-temperature battery) -5°C to 75°C (high-temperature battery) |
||
| Operating humidity | 5% to 95% | ||
| LED indicator | Green indicator showing the GSM signal Blue indicator showing the GPS signal |
||
| Button/Switch | 1 SOS button (for sending SMSs or dialing) 1 power button |
||
| Memory | 8 MB buffer | ||
| Sensor | 3-axis accelerometer (used to wake the device up by vibration and detect towing alerts) | ||
| Frequency band | T333L: LTE-FDD: B1/B3/B5/B7/B8/B20/B28 LTE-TDD: B38/B40/B41 GSM: B2/B3/B5/B8 |
||
| Positioning accuracy | 2.5m | ||
| I/O port | 3 digital inputs (2 negative inputs and 1 positive input) 2 analog detection inputs 2 outputs 1 RS232 port 1 USB port 1-Wire® iButton 1-Wire® temperature sensor |
ACCESSORIES
| T333L with a built-in battery | I/O cable + SOS button | External 4G antenna | |||
| External GPS antenna | CD download card |
OPTIONAL ACCESSORIES
| Camera | Speaker and microphone | RFID reader | |||
| iButton | A53 fuel level sensor | Ultrasonic fuel level sensor | |||
| Tire pressure sensor | A52 digital temperature sensor + A61 sensor box | LED display | |||
| USB cable |
