iridium gps tracker

FEATURES

Smiley face
Iridium Network
Once a GSM signal cannot be detected, the Iridium network is switched automatically.
SBD
Iridium SBD
As a VAR of Iridium, Meitrack offers Iridium SBD Airtime Service, thus truly achieving data connectivity anywhere in the world.
1
CAN Bus Interface
Has CAN bus interface which can read CAN data
of various vehicle models.
screen
Multi-functional
Support CAN bus, relay, ultrasonic fuel level sensor, camera, RFID reader and etc.

APPLICATIONS

iridium GPS tracker

SPECIFICATIONS

Dimension 105 mm x 65 mm x 26 mm
Weight 190g
Power supply DC 11.4–36 V/1.5 A
Backup battery 400 mAh/3.7V
Power consumption Current in sleep mode: 11 mA
Operating temperature -10°C to 55°C
Operating humidity 5% to 95%
Working hour 45 hours in power-saving mode
4 hours in normal mode
LED indicator Green indicator showing the GSM signal
Blue indicator showing the GPS signal
Button/Switch 1 power button
Sensor 3-axis accelerometer (used to wake the device up by vibration and detect towing alerts)
Memory 8 MB buffer
Iridium satellite Frequency band: 1616–1626.5 MHz
Duplex mode: TDD
Multiplexing mode: TDMA/FDMA
GNSS GPS
GPS sensitivity -161 dB
Positioning accuracy 2.5m
I/O port 3 x Din, 1 x Dout, 1 x RS232, 1 x USB, 1 x CAN
Frequency band T622G-F9:
UMTS/HSDPA: 800/850/900/1900/2100 MHz
GSM/GPRS: 850/900/1800/1900 MHz
T622E-F9:
LTE CAT M1/NB: B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26/B27/B28/B66/B71/B85
GSM/GPRS: 850/900/1800/1900 MHz

ACCESSORIES

T622 Series tracker External GPS antenna External 3G/4G antenna
External Iridium antenna I/O cable(1 meter, without SOS button) Micro serial USB cable
CD download card

OPTIONAL ACCESSORIES

SOS button Relay (12 V/24 V) RFID reader
Camera Ultrasonic fuel level sensor

CERTIFICATE

CE, TELEC
